DSBOX-NX2 can decode up to 32 video streams in 1080p at 30 FPS with its powerful NVIDIA Jetson Xavier™ NX processor. Xavier™ NX processor delivers 21 TOPS AI performance with its 384 NVIDIA CUDA® Cores, 48 Tensor Cores, 6 Carmel ARM CPUs, and two NVIDIA Deep Learning Accelerators (NVDLA) engines. With its support for deep learning-based algorithms, DSBOX-NX2 enables users to process signals, videos, or device sensor information, and send commands to actuators, cobots, or LEDs.
With the help of NVIDIA's DeepStream SDK, you can achieve maximum performance on simultaneous video processing applications. You can achieve up to 275 FPS for Resnet-34 based people detection, 362 FPS for RESNET-18 based people detection, 474 FPS for RESNET-18 based vehicle detection and 2298 FPS for RESNET-18 based face detection algorithms with full utilization of GPU together with two DLA engines. Benchmark details can be found at NVIDIA’s DeepStream SDK website. These benchmarks show that DSBOX-NX2 is your edge AI deployment system for multiple stream video processing applications based on deep learning algorithms.
DSBOX-NX2 offers a rich set of industrial connectivity options, making it easy to connect with any industrial system, production line, or network. The high-speed interfaces such as Gigabit Ethernet and USB 3.1 enable users to connect to PLC systems, servo motor controllers, sensors, actuators, and even vehicle information networks using the CAN BUS interface. The digital inputs and outputs are also available to initiate detection and recognition processes, or direct signal passing based on algorithm findings.
Additionally, DSBOX-NX2's multi-protocol serial port can be configured using internal GPIO configuration commands, providing users with even greater flexibility and ease of use. DSBOX-NX2's hardware design is optimized to deliver maximum throughput to its users. Each trace is carefully designed to ensure that the high-speed interfaces, including PCI Gen 4 support for M.2 Key-M SSD connections, Gigabit Ethernet, USB 3.1, andM.2 Key-B with USB 3.1 connection, perform at their best. DSBOX-NX2 is thoroughly tested to ensure that its high-speed interfaces perform at their maximum throughput without any degradation.
DSBOX-NX2 provides a field-proven mechanical design for its users. It is elegant, durable, and cool even after long operations under heavy CPU and GPU utilization. With its extended operating temperature range of -25⁰C to +65⁰C, you can use DSBOX-NX2 in any industrial environment. Mechanical mounting options are well-thought during the design of DSBOX enclosure. You can use it on the desk as your development computer for next edge AI project, mount to wall or a surface using the screw holes on the flanges or even can mount to a standard rail using the supplied rail mount adapter.
Thermal performance is guaranteed with its unique mechanical design. After 24 hours of heavy operation with maximum CPU and GPU utilization, internal CPU temperature does not exceed 70⁰C. With its guaranteed thermal performance. DSBOX-NX2 never reaches thermal throttling points of processor and never drops its performance.
DSBOX-NX2 provides a wide range voltage input together with reliability. You can connect any power supply between 9-28 VDC range and it will work for weeks and mounts without any issues. Even under long hours of maximum CPU and GPU loads. the power design is always stable and never causes an interruption. Achieving this reliability is never easy. From board stack up to circuit design and component selection, every step is realized very carefully.
Our ten years’ experience on hardware design and six years’ experience on designing carrier boards and hardware systems based on NVIDIA® Jetson™ modules starting from Jetson™ TX1 series up to Jetson AGX Xavier™ and Jetson Xavier™ NX series helped us achieving this performance as well. Beside power circuit reliability, power connection reliability is another important aspect in industrial systems. With our screw locked industrial grade power connectors, you will never have an operation interruption caused by connection issues.
Supported Modules | NVIDIA Jetson Xavier NX 8GB / 16GB |
Memory | 8 GB 128-bit LPDDR4x / 16 GB 128-bit LPDDR4x |
Graphics Interfaces | 1x HDMI 2.0 (max resolution 3840x2160) |
Interfaces | 1x Gigabit Ethernet 2x USB 3.1 Type-A 1x CAN Bus (Only in Xavier NX and TX2NX SoM) 1x RS232/422/485 (software configurable) 1x microUSB 2.0 (Recovery) 2x Digital Input, 3x Digital Output |
Wireless Communication | WiFi/Bluetooth/LTE/5G Connectivity by extension sockets |
Power Supply | 9-28 VDC |
Extension Sockets | 1x M.2 Key-E, 1x M.2 Key-B, 1x MicroSD, 1x SIM |
Mass Storage | 16 GB eMMC 5.1 Flash 1x M.2 Key-M SSD Slot |
Ambient Conditions | -25°C ... +65°C |
Form Factor / Dimensions | 110 mm x 130 mm x 60 mm, 760 gr |
Operating Systems | Ubuntu Linux 18.04 / 20.04 |
JetPack Support | JetPack 4.x (4.4.1 / 4.5 / 4.5.1 / 4.6 / 4.6.1 / 4.6.2 / 4.6.3) JetPack 5.x (5.0.2 / 5.1) |
