Cost-Effective Edge AI Deployments with NVIDIA Jetson Carrier Boards


The DSBOARD-AGX is designed to maximize the potential of the NVIDIA Jetson AGX Orin™ SoM, providing an ideal platform for high-performance AI and machine learning applications. With support for up to six high-resolution cameras, multiple displays, and a wide range of I/O options, the DSBOARD-AGX is the perfect choice for developers looking to take their applications to the next level. With up to 275 TOPS of AI performance, this device delivers the processing power needed to run complex algorithms and neural networks.

DSBOARD-AGX is a powerful and reliable edge computing device designed for industrial applications that require high processing power and ruggedness with it features an NVIDIA Ampere GPU with 1024 CUDA cores, also includes a 12-core ARMv8.2 CPU and a dedicated deep learning accelerator for efficient inferencing.


The DSBOARD-AGX is a highly beneficial platform for AI and machine learning development thanks to its exceptional computing performance and advanced deep learning accelerator engines. DSBOARD-AGX runs on the NVIDIA JetPack™ SDK, providing a complete software development environment for building and deploying AI applications in industrial environments. With support for NVIDIA's powerful Tensor Cores, this carrier board offers unrivaled performance and efficiency, making it an ideal platform for developing AI and machine learning applications that demand high computational power.

With its powerful Jetson AGX Orin™ SOM, the DSBOARD-AGX is capable of running complex AI algorithms and processing large amounts of data in real-time, making it an ideal choice for industrial applications such as robotics, automation, and surveillance.

Entire NVIDIA Jetson Family Supported
Rich Industrial Connectivity with RS-232, RS-485, CAN and Gigabit Ethernet


Featuring six high-resolution camera inputs, multiple displays, and a wide range of I/O options, the DSBOARD-AGX is the perfect platform for developers working on demanding applications in industries such as autonomous vehicles, robotics, and industrial automation. With its advanced features and powerful performance, the DSBOARD-AGX is the ideal choice for developers looking to push the boundaries of what's possible with AI and machine learning.

The Jetson AGX Orin™ runs Ubuntu Linux 20.04 as its operating system and is supported byJetPack 5.x (5.0.2/5.1) for software development and deployment. It also has a camera connector that supports up to 6 CSI cameras.


The DSBOARD-AGX is designed with ease of use and deployment in mind, featuring a user-friendly interface and a wide range of pre-built software tools and libraries. With support for popular development frameworks such as TensorFlow, PyTorch, andCaffe, the DSBOARD-AGX makes it easy for developers to get started and create advanced AI and machine learning applications. The DSBOARD-AGX comes pre-loaded with the NVIDIA JetPack™ SDK, which includes a suite of software tools and libraries for AI and machine learning development.

The DSBOARD-AGX features a wide range of connectivity options, including Gigabit Ethernet, USB3.0, HDMI, and RS-232, as well as multiple expansion slots for adding additional peripherals such as MIPI CSI2 cameras.

Designed For High Speed Applications such as PCIE Gen4, USB3.1
Reliable & Efficient Power Circuit Design


With its advanced features and cutting-edge technology, the DSBOARD-AGX is designed to meet the needs of tomorrow's AI and machine learning applications. Whether you're working on autonomous vehicles, robotics, or industrial automation, the DSBOARD-AGX is the perfect platform for developing advanced solutions that will shape the future of AI and machine learning.

Designed for harsh industrial environments, DSBOARD-AGX is rugged and durable. It can operate within a wide temperature range and is resistant to shock, vibration, and other environmental stressors. This makes it an ideal choice for applications such as robotics, automation, and surveillance, where reliability and performance are critical.


Technical Specifications

Supported Modules

NVIDIA Jetson AGX Orin 32GB

NVIDIA Jetson AGX Orin 64GB


32 GB 256-bit LPDDR5x

64 GB 256-bit LPDDR5x

Graphics Interfaces1x HDMI 2.0 (max resolution 3840x2160)

1x Gigabit Ethernet

2x USB 3.1 Type-A

1x CAN Bus

1x RS232/422/485 (software configurable)

2x USB-C (Debug/Recovery)

2x Digital Input, 3x Digital Output

Wireless CommunicationWiFi/LTE/5G Connectivity by extension sockets
Power Supply12-32 VDC
Extension Sockets

1x M.2 Key-B, 1x SIM, 1x MicroSD, 1x 5V Fan, 1x SPI, 1x UART, 1x I2C, 1x PCIE (x4), 1x I2S, 1 x XFI for 10G

1x Camera Connector (6 CSI camera support)

Mass Storage

64 GB eMMC 5.1 Flash

1x M.2 Key-M SSD Slot

Ambient Conditions-25°C … +85°C
Form Factor / Dimensions100 mm x 100 mm, 103 gr
Operating SystemsUbuntu Linux 20.04
JetPack SupportJetPack 5.x (5.0.2 / 5.1)
