Supercomputer Level AI Performance with NVIDIA Jetson AGX Xavier Module

TOP PERFORMANCE ON AI

DSBOARD-XV2 is designed to deliver top performance on AI deployments, with its powerful hardware, optimized software, and comprehensive connectivity options making it the perfect choice for industrial applications that require high processing power and reliability.


DSBOARD-XV2 is an industrial grade carrier board designed to support the NVIDIA Jetson AGX Xavier™ processor with a NVIDIA Volta™ GPU and an eight-core ARM64 CPU, it offers up to 32 TOPS of compute performance for deep learning and computer vision tasks. It has a compact form factor of 100 mm x 100 mm and weighing in at just 103 grams, this carrier board packs a powerful punch with its extensive list of features.


TRANSFER  EFFICIENCY

DSBOARD-XV2 supports both Jetson AGX Xavier™ and Jetson AGX Xavier™ Industrial with all the features. We provide the most recent release of BSP packages of NVIDIA JetPack™ that NVIDIA provides. As FORECR, we also provide solutions to mechanical integration problems for our customers at the carrier board level. To make the Jetson™ modules work efficiently even under maximum loads, we created a thermal transfer plate option.


When you order DSBOARD-XV2 with a module option, the suitable thermal transfer unit and screw set will be included in the package. We integrate the module and mechanical parts to the carrier board, flash the recent Jetpack software, and our BSP package to deliver a ready-to-use system to your hands.


Designed to be compliant with MIL-STD Military Standards
Rich Connection Interfaces (8xUART, 5x Gigabit Ethernet, 2x CAN)

HIGH LEVEL INTERCONNECTIVITY

The device also boasts multiple connectivity options, including Gigabit Ethernet, Wi-Fi, Bluetooth, and USB 3.2, as well as M.2 expansion slots and a microSD card slot for storage expansion. Its wide operating temperature and input voltage range make it highly adaptable to various industrial environments, from robotics to transportation, security, and surveillance.


DSBOARD-XV2 is designed to be used in various industries so we included board-level connectors and rich camera connections as well. DSBOARD-XV2 supports up to six MIPI CSI-2 camera connections compatible with standard Raspberry Pi pinout. Additional board-level connectors with UART, SPI, I2C, PCIe signals are also available.


MAXIMUM SPEED

To utilize the DSBOARD-XV2 with maximum speed, it is recommended to pair it with the NVIDIA Jetson AGX Xavier™ module, which is designed to deliver high-performance computing for artificial intelligence and deep learning applications. Additionally, to achieve maximum speed, it is recommended to use the DSBOARD-XV2 with optimized software, such as JetPack™  4.x or JetPack™  5.x. which include optimized libraries, APIs, and tools that are specifically designed to take advantage of the power of the NVIDIA Jetson AGX Xavier™  module.


DSBOARD-XV2 has 4x PCI Gen 4 support for M.2 Key-M SSD slot, Gigabit Ethernet, 2x USB 3.1 and M.2 Key-B with USB 3.1 connection. Together with these interfaces, board level MIPI CSI-2 interfaces and SD Card interfaces are available as high-speed interfaces. All are tested by our engineering team prior to the shipment. We make sure that the performance of our carrier boards is stable and at the maximum efficiency before deliver to our customers.


Maximum Speed on High Speed Interfaces (Gigabit Ethernet, USB 3.2, PCIE SSD))
Reliable & Robust Power Design with Wide Input Voltage Range

LONG ENDURANCE

The DSBOARD-XV2 is designed to operate with a wide input voltage range of 18-30 VDC. This allows it to be powered by a wide range of power sources in different industrial usage. Its wide operating temperature range of -25°C to +85°C also make DSBOARD-XV2 ideal for deployment in various industrial settings.


Compact yet rugged, the DSBOARD-XV2 is built to withstand even the toughest industrial conditions, making it an ideal choice for applications that require both high-performance computing and reliable connectivity. So, whether you're working in industrial automation, healthcare, or any other industrial field, the DSBOARD-XV2 is the edge computing device you need to take your applications to the next level.


Technical Specifications

Supported Modules

NVIDIA Jetson AGX Xavier 32GB

NVIDIA Jetson AGX Xavier 64GB

NVIDIA Jetson AGX Xavier Industrial 32GB

Memory32 / 64 GB 256-bit LPDDR4x
Graphics Interfaces1x HDMI 2.0 (max resolution 3840x2160)
Interfaces

1x Gigabit Ethernet

2x USB 3.1 Type-A

1x CAN Bus

1x RS232/422/485 (software configurable)

2x Type-C (Debug/Recovery)

2x Digital Input, 3x Digital Output

6X CSI 2-LANE

Wireless CommunicationWiFi/Bluetooth Connectivity by extension sockets
Power Supply18-30 VDC
Extension Sockets1x M.2 Key-E, 1x MicroSD, 1x 5V Fan, 1x PCIE(x8), 1x PCIE(x1), 1x CAN, 1x UART, 1x SPI, 1x I2C, 1x DP
Mass Storage

32 / 64 GB eMMC 5.1 Flash

1x M.2 Key-M SSD Slot

Ambient Conditions-25°C … +85°C
Form Factor / Dimensions100 mm x 100 mm, 103 gr
Operating SystemsUbuntu Linux 18.04 / 20.04
JetPack Support

JetPack 4.x (4.4.1 / 4.5 / 4.5.1 / 4.6 / 4.6.1 / 4.6.2 / 4.6.3)

JetPack 5.x (5.0.2 / 5.1)
